GE Power Quality Meter Series User Manual

GE Power Management PQM Power Quality Meter 7-43
7 MODBUS COMMUNICATIONS 7.3 MODBUS MEMORY MAP
7
ANALOG
OUTPUT 2
continued
106D Analog Output 2 Alternate Max Value See Analog Output Range Table on page 7–63 0
106E Reserved
106F Analog Output 2 Serial Value 1 --- F2 0
ANALOG
OUTPUT 3
1070 Analog Output 3 Main Type 0 to 59 1 --- F14 0=NOT USED
1071 Analog Output 3 Main Min Value See Analog Output Range Table on page 7–63
1072 Analog Output 3 Main Max Value See Analog Output Range Table on page 7–63
1073 Analog Output 3 Alternate Type 0 to 59 1 --- F14 0=NOT USED
1074 Analog Output 3 Alternate Min Value See Analog Output Range Table on page 7–63
1075 Analog Output 3 Alternate Max Value See Analog Output Range Table on page 7–63
1076 Reserved
1077 Analog Output 3 Serial Value 1 --- F2 0
ANALOG
OUTPUT 4
1078 Analog Output 4 Main Type 0 to 59 1 --- F14 0=NOT USED
1079 Analog Output 4 Main Min Value See Analog Output Range Table on page 7–63
107A Analog Output 4 Main Max Value See Analog Output Range Table on page 7–63
107B Analog Output 4 Alternate Type 0 to 59 1 --- F14 0=NOT USED
107C Analog Output 4 Alternate Min Value See Analog Output Range Table on page 7–63
107D Analog Output 4 Alternate Max Value See Analog Output Range Table on page 7–63
107E Reserved
107F Analog Output 4 Serial Value 1 --- F2 0
ANALOG
INPUT
1080 Analog Input Main/Alt Select Relay 0 to 3 1 --- F19 0=OFF
1081 Analog In Main Name 1
st
and 2
nd
char. --- --- ASCII F10 ““
1082 Analog In Main Name 3
rd
and 4
th
char. --- --- ASCII F10 “MA”
1083 Analog In Main Name 5
th
and 6
th
char. --- --- ASCII F10 “IN”
1084 Analog In Main Name 7
th
and 8
th
char. --- --- ASCII F10 “ A”
1085 Analog In Main Name 9
th
and 10
th
char. -- -- ASCII F10 “NA”
1086 Analog In Main Name 11
th
and 12
th
char. -- -- ASCII F10 “LO”
1087 Analog In Main Name 13
th
and 14
th
char. --- --- ASCII F10 “G “
1088 Analog In Main Name 15
h
and 16
th
char. ---- ---- ASCII F10 “IN”
1089 Analog In Main Name 17
th
and 18
th
char. --- --- ASCII F10 “PU”
108A Analog In Main Name 19
th
and 20
th
char. --- --- ASCII F10 “T “
108B Analog In Main Units 1
st
and 2
nd
char. --- --- ASCII F10 “ U”
108C Analog In Main Units 3
rd
and 4
th
char. --- --- ASCII F10 “ni”
108D Analog In Main Units 5
th
and 6
th
char. --- --- ASCII F10 “ts”
108E Analog In Main Units 7
th
and 8
th
char. --- --- ASCII F10 “”
108F Analog In Main Units 9
th
and 10
th
char. --- --- ASCII F10 ““
1090 Analog Input Main 4 mA Value 0 to 65000 1 --- F1 0
1091 Analog Input Main 20 mA Value 0 to 65000 1 --- F1 0
1092 Analog Input Main Relay 0 to 4 1 --- F29 0=OFF
1093 Analog Input Main Level 0 to 65000 1 --- F1 0
1094 Analog Input Main Delay 5 to 6000 5 0.1 xs F1 100=10.0 s
1095 Reserved
1096 Reserved
1097 Reserved
1098 Analog In Alt Name 1
st
and 2
nd
char. --- --- ASCII F10 ““
Table 7–10: PQM MEMORY MAP (Sheet 29 of 40)
GROUP ADDR
(HEX)
DESCRIPTION RANGE STEP
VALUE
UNITS and
SCALE
FORMAT FACTORY DEFAULT
Notes: * Data type depends on the Command Operation Code. ** Any valid Actual Values or Setpoints address.
*** Maximum Setpoint value represents “OFF”. **** Minimum Setpoint value represents “OFF”.
***** Maximum Setpoint value represents “UNLIMITED”.
