Section 11 — Balancing Rotors
228
Combine/Adjust Weights
To combine and adjust weights:
1. Take a trim reading.
2. Press to display the Balance Weight menu (or Balance
Readings from the Balancing menu).
3. Press the arrow key on the left beside Plane A or B.
4. Press Adjust Weights — The Adjust Weights menu displays the
locations and amounts of your individual trim weights, the weight
vector (Existing Total), and the target weight and angle (the trim
weight/angle solution you hope to achieve).
5. Use the arrow keys on the left to select one of the trim weights you
want to remove.
6. Press Remove or Keep — The calculator will recalculate the
suggested weight/angle.
NOTE: You can experiment with different remove/keep
combinations by repeating this process. Press again to add a
subtracted weight back to the calculator.
7. Press when you are satisfied with the suggested weight
calculation.
Combine and adjust weights
