Section 4 — Measurement Types and their Uses
78
Review Data in ODS software
If you are using ODS software such as ME’scope, you can import the
modal impact and Cross Channel Spectrum (ODS) data stored on your
instrument into this program and conduct a more detailed analysis.
When importing modal impact data into ODS software such as
ME’scope, construct the model using the sketch you drew, along with the
numbered points.
To review the data in ODS software such as ME’scope:
1. Securely connect a USB flash drive to your instrument's USB host
port.
TIP: Ensure the USB flash drive you are using has enough storage
space and that any write protect tabs are unlocked.
2. Press Folders & USB Export on the main menu — The USB
Flash Drive screen opens.
NOTE: If you have NOT yet attached a USB flash drive, do this now
and press USB Flash Drive.
3. Press to export the data in Universal File Format (UFF) format.
4. Use the navigation buttons to select the required machine > Press
.
5. Use the navigation buttons to select the required modal impact or
Cross Channel Spectrum (ODS) recordings > Press .
6. Disconnect the flash drive.
7. Connect the memory stick to the PC running the ODS software.
8. Use the standard data import functionality provided in the ODS
software to import the data.
