GE Venue Fit - Touch Display Assembly Replacement Procedure; Tools; Time Required; Preparations

DIRECTION 5854713-100, REVISION 2 VENUE FIT™ SERVICE MANUAL
Chapter 8 - Replacement Procedures 8-23
PRELIMINARY
8-2-10 Touch Display Assembly Replacement Procedure
8-2-10-1 Tools
Phillips screwdriver of appropriate size
8-2-10-2 Time Required
5 min
8-2-10-3 Preparations
1.) Shut down the Venue Fit™ ultrasound unit, as described in Power Shutdown.
2.) Prepare stable flat surface covered with a soft material (such as foam or thick cloth) to prevent
scratches to the display.
3.) Dismount Venue Fit™ system from cart as described in Mounting / Dismounting System on Cart
and place it on a previously prepared surface with the display facing down.
8-2-10-4 Front Display Assembly Removal Procedure
1) Remove Rear cover.
2.) Remove the Speakers.
3.) Remove the M-PSB.
4) Remove the fan.
5.) Remove the M-BEB.
6.) Remove the C-FEB
• Rear Cover Removal Procedure
• Speakers Removal Procedure
• M-PSB Removal Procedure
• Fan Removal Procedure
• M-BEB Removal Procedure
• C-FEB Removal Procedure
