150 ADV200 • Quick start up guide
268 [10.55”]
682 [26.85 ”]
270 [10.63 ”]
682 [26.85 ”] 616 [24.25 ”]
612 [24.09 ”]
Figure 9.10.5: Size 4 dimensions (ADV200-...-4)
268 [10.55”]
270 [10.63”]
616 [24.25”]
612 [24.09”]
Figure 9.10.6: Size 4 dimensions (ADV200-...-4-DC)
