gefran installationSIEIDrive ADL300 User Manual

ADL300 • Quick installation guide - Specifications and connection 103
03 STARTUP WIZARD
Run phasing still?
E=Yes Down=Next
E
SEQ
01 PAR: 2192
Autotune still
Press E to exe
c
ute
E
Auto
t
une
Progress 0%
Close Enable in
p
ut
Auto
t
une
Progress 10%
Press ESC to abort
(1) (2) (3) (4)
Auto
t
une
Progress 100%
Open Enable in
p
ut
Auto
t
une
Done
(5)
(1) Press the E key to proceed to the autotune procedure.
(2) Press the E key to start the autotune procedure.
(3) Enable the drive by connecting terminal 9 on the I/O card (Enable) to terminal 12 (+24 V). To abort this operation,
press the ESC key.
(4) Once the drive is enabled the autotune procedure starts. This may take a few minutes, depending on the type of
motor being used.
(5) At the end of the procedure the following screen is displayed. After opening the Enable contact, proceed to step 6.
Step 6 - Setting the maximum speed reference value and system speed
Setting the maximum speed reference value: this denes the maximum motor speed value (in rpm) that can be
reached with each single reference signal (analog or digital).
03 STARTUP WIZARD
Set max motor speed?
E=Yes Down=Next
E
SEQ
01 PAR: 680
Full scale speed
120 rpm
Def: 120
E
SEQ
01 PAR: 680
Full scale speed
000000120 rpm
Def: 120
▲
121 rpm
▼
119 rpm
E
Set the maximum system speed in m/s
03 STARTUP WIZARD
Set max car speed?
E=Yes Down=Next
E
SEQ
01 PAR: 11006
Contact speed
1.0 m/s
Def: 1.0
E
SEQ
01 PAR: 11006
Contact speed
0000001.0 m/s
Def: 1.0
▲
1.1 m/s
▼
0.9 m/s
E
After setting the speed, proceed to step 7 to set the system weights.
Note! The factory (default) setting depends on the size of the drive that is connected. These values refer to the ADL..-1055-BR
Step 7 - Setting the system weights
The system weights must be entered in this part of the wizard procedure.
03 STARTUP WIZARD
Set system weights?
E=Yes Down=Next
E
SEQ
01 PAR: 11150
Cabin weight
0 kg
Def: 0
E
SEQ
01 PAR: 11150
Cabin weight
000000000 kg
Def: 0
▲
1 kg
▼
0 kg
E

SEQ
02 PAR: 11152
Counterweight
0 kg
Def: 0
E
SEQ
02 PAR: 11152
Counterweight
000000000 kg
Def: 0
▲
1 kg
▼
0 kg
E

SEQ
03 PAR: 11154
Max load weight
0 kg
Def: 0
E
SEQ
03 PAR: 11154
Max load weight
000000000 kg
Def: 0
▲
1 kg
▼
0 kg
E
