ADL300 • Quick installation guide - Specifications and connection 91
SEQ
02 PAR: 2102
Encoder supply
5.2 V
Def: 5.2
E
SEQ
02 PAR: 2102
Encoder supply
0000005.2 V
Def: 5.2
▲
5.3 A
▼
5.1 A
E
Step 5 – Encoder phasing
Not available in this mode.
Step 6 - Setting the maximum speed reference value and system speed
Setting the maximum speed reference value: this denes the maximum motor speed value (in rpm) that can be
reached with each single reference signal (analog or digital).
03 STARTUP WIZARD
Set max motor speed?
E=Yes Down=Next
E
SEQ
01 PAR: 680
Full scale speed
1440 rpm
Def: 1440
E
SEQ
01 PAR: 680
Full scale speed
000001440 rpm
Def: 1440
▲
1441 rpm
▼
1439 rpm
E
Set the maximum system speed in m/s
03 STARTUP WIZARD
Set max car speed?
E=Yes Down=Next
E
SEQ
01 PAR: 11006
System s
p
eed
1.0 m/s
Def: 1.0
E
SEQ
01 PAR: 11006
System s
p
eed
0000001.0 m/s
Def: 1.0
▲
1.1 m/s
▼
0.9 m/s
E
After setting the speed, proceed to step 7 to set the system weights.
Note! The factory (default) setting depends on the size of the drive that is connected. These values refer to the ADL..-1055-AC
Step 7 - Setting the system weights
The system weights must be entered in this part of the wizard procedure.
03 STARTUP WIZARD
Set system weights?
E=Yes Down=Next
E
SEQ
01 PAR: 11150
Weight of cabin
0 kg
Def: 0
E
SEQ
01 PAR: 11150
Weight of cabin
000000000 kg
Def: 0
▲
1 kg
▼
0 kg
E
SEQ
02 PAR: 11152
Counterweight
0 kg
Def: 0
E
SEQ
02 PAR: 11152
Counterweight
000000000 kg
Def: 0
▲
1 kg
▼
0 kg
E
SEQ
03 PAR: 11154
Max load weight
0 kg
Def: 0
E
SEQ
03 PAR: 11154
Max load weight
000000000 kg
Def: 0
▲
1 kg
▼
0 kg
E
SEQ
04 PAR: 11156
Cable weight
0 kg
Def: 0
E
SEQ
04 PAR: 11156
Cable weight
000000000 kg
Def: 0
▲
1 kg
▼
0 kg
E
SEQ
05 PAR: 11158
Reducer inertia
0 kgm²
Def: 0
E
SEQ
05 PAR: 11158
Reducer inertia
000000000 kgm²
Def: 0
▲
1 kgm²
▼
0 kgm²
E
