92 ADL300 • Quick installation guide - Specifications and connection
SEQ
06 PAR: 11160
Motor inertia
0 kgm²
Def: 0
E
SEQ
06 PAR: 11160
Motor inertia
000000000 kgm²
Def: 0
1 kgm²
0 kgm²
E
After setting the mechanical measurements, proceed to the next step.
Step 8 - Setting application parameters
The application data can be entered at this stage.
Set the multispeed values
03 STARTUP WIZARD
Set application par?
E=Yes Down=Next
E
SEQ
01 PAR: 11002
Spd unit of measure
Hz
Def: 0
E
SEQ
01 PAR: 11002
Spd unit of measure
Hz
Def: 0
rpm
m/s
E
SEQ
02 PAR: 11020
Multispeed 0
5 Hz
Def: 5
E
SEQ
02 PAR: 11020
Multispeed 0
000000005 Hz
Def: 5
6 Hz
4 Hz
E
SEQ
03 PAR: 11022
Multispeed 1
45 Hz
Def: 45
E
SEQ
03 PAR: 11022
Multispeed 1
000000045 Hz
Def: 45
46 Hz
44 Hz
E
SEQ
04 PAR: 11024
Multispeed 2
20 Hz
Def: 20
E
SEQ
04 PAR: 11024
Multispeed 2
000000020 Hz
Def: 20
21 Hz
19 Hz
E
SEQ
05 PAR: 11026
Multispeed 3
0 Hz
Def: 0
E
SEQ
05 PAR: 11026
Multispeed 3
000000000 Hz
Def: 0
1 Hz
0 Hz
E
SEQ
06 PAR: 11028
Multispeed 4
0 Hz
Def: 0
E
SEQ
06 PAR: 11028
Multispeed 4
000000000 Hz
Def: 0
1 Hz
0 Hz
E
Multi speed conguration table:
Through the combination of “MtlSpd S0” (Digital input 4), “MtlSpd S1” (Digital input 5) and “MtlSpd S2” (Digital input
6) commands, is possible to select Multi speed desired, according to next table:
MtlSpd S2 MtlSpd S1 MtlSpd S0 ACTIVE SPEED
0 0 0 Multispeed 0, PAR 11020
0 0 1 Multispeed 1, PAR 11022
0 1 0 Multispeed 2, PAR 11024
0 1 1 Multispeed 3, PAR 11026
1 0 0 Multispeed 4, PAR 11028
1 0 1 Multispeed 5, PAR 11030
1 1 0 Multispeed 6, PAR 11032
1 1 1 Multispeed 7, PAR 11034
Attention
