● Set the ramp values

SEQ
07 PAR: 11040
Acc start jerk
0.5 m/s³
Def: 0.5
E
SEQ
07 PAR: 11040
Acc start jerk
00000000.5 m/s³
Def: 0.5
▲
0.6 m/s³
▼
0.4 m/s³
E

SEQ
08 PAR: 11042
Acceleration
0.6 m/s²
Def: 0.6
E
SEQ
08 PAR: 11042
Acceleration
00000000.6 m/s²
Def: 0.6
▲
0.7 m/s²
▼
0.5 m/s²
E

SEQ
09 PAR: 11044
Acc nal jerk
1.4 m/s³
Def: 1.4
E
SEQ
09 PAR: 11044
Acc nal jerk
00000001.4 m/s³
Def: 1.4
▲
1.5 m/s³
▼
1.4 m/s³
E

SEQ
10 PAR: 11046
Dec start jerk
1.4 m/s³
Def: 1.4
E
SEQ
10 PAR: 11046
Dec start jerk
00000001.4 m/s³
Def: 1.4
▲
1.5 m/s³
▼
1.4 m/s³
E

SEQ
11 PAR: 11048
Deceleration
0.6 m/s²
Def: 0.6
E
SEQ
11 PAR: 11048
Deceleration
00000000.6 m/s²
Def: 0.6
▲
0.7 m/s²
▼
0.5 m/s²
E

SEQ
12 PAR: 11050
Dec nal jerk
0.5 m/s³
Def: 0.5
E
SEQ
12 PAR: 11050
Dec nal jerk
00000000.5 m/s³
Def: 0.5
▲
0.6 m/s³
▼
0.4 m/s³
E

SEQ
13 PAR: 11052
Stop decel
0.7 m/s²
Def: 0.7
E
SEQ
13 PAR: 11052
Stop decel
00000000.7 m/s²
Def: 0.7
▲
0.8 m/s²
▼
0.6 m/s³
E
● Set the distance values

SEQ
14 PAR: 11104
Dist multilevel 1
0 m
Def: 0
E
SEQ
14 PAR: 11104
Dist multilevel 1
000000000 m
Def: 0
▲
1 m
▼
0 m
E

SEQ
15 PAR: 11162
Calc spd reg gains
Disabled
E
SEQ
15 PAR: 11162
Calc spd reg gains
Disabled
▲
Enabled
▼
Enabled
E
Next proceed to step 9 to save the system parameters that have been entered and those calculated by the drive using
the autotune and automatic phasing procedures.
Step 9 - Save parameters
To save the new parameter settings, so that they are maintained also after power-off, proceed as follows:
03 STARTUP WIZARD
Save parameters?
E=Yes Down=Next
E
SEQ
01 PAR: 550
Save parameters?
Press E to exe
c
ute
E
SEQ
01 PAR: 550
Save parameters?
Do
n
e
03 STARTUP WIZARD
End of se
q
uence
Up=Back Down=Exit
