General Dynamics C4 Systems URC-200 (V2)
93
3. Preset the R2600 by performing the following steps.
a. Press the MEM (Memory) key on the R2600 panel for the preset-screen.
b. Use the CURSOR POSITION keys to highlight preset 06.
c. Press the "view preset" soft key.
NOTE
The soft keys are the eight keys under the CRT screen on the R2600.
d. Use the CURSOR POSITION keys to the Monitor Frequency position and enter 299.975
from the R2600 keypad.
e. Move the cursor to Modulation Type and press the "FM" soft key.
f. Move the cursor to the Generate Frequency position and enter 299.975 from the R2600
keypad.
g. Move the cursor to Modulation Type and press the "FM" soft key.
h. Move the cursor to bandwidth and press the "NARROW ±5 kHz" soft key.
i. Move the cursor to the Duplex Offset position and press the "DON'T CARE" soft key.
j. Move the cursor to Synth. Format Sel (synthesizer format select) and select the "Tone A"
soft key.
k. Move the cursor to Freq (frequency) and enter 01000.0 from the keypad.
l. Move the cursor to the DTMF Code position and press the "DON'T CARE" soft key.
NOTE
The “more” soft key may have to be depressed for the “DON’T CARE” soft
key to be displayed.
m. Press the "return" soft key. Repeat steps A through K for presets 07 and 08. Use Table 21
to program the frequency presets in steps D and E above.
n. Press the "return" soft key.
4. Perform the following steps to complete the setup on the R2600 analyzer.
a. Press RF key on the R2600 panel. Move the cursor to RF Control and press the "GEN"
soft key.
b. Move the cursor to the Output Lvl (RF Output Level) position and enter a level of -080.0
dBm from the keypad.
c. Move the cursor to the Gen RF Out position and press the "RF IN/OUT" soft key.
d. Depress the AUD (Audio) key on the R2600 panel. Move the cursor to the Synth
(Synthesizer) position and enter 6.50 kHz from the keypad.
NOTE
This is FM Deviation. Depress the RIGHT ARROW CURSOR CONTROL
key and depress “Cont” (Continuous) soft key.
