General Dynamics C4 Systems URC-200 (V2)
85
d. Use the CURSOR POSITION keys to the Monitor Frequency position and enter 115.000
from the R2600 keypad.
e. Move the cursor to Modulation Type and press the "AM" soft key.
f. Move the cursor to the Generate Frequency position and enter 115.000 from the R2600
keypad.
g. Move the cursor to Modulation Type and press the "AM" soft key.
h. Move the cursor to bandwidth and press the "NARROW ±5 kHz" soft key.
i. Move the cursor to the Duplex Offset position and press the "DON'T CARE" soft key.
j. Move the cursor to Synth. Format Sel (synthesizer format select) and select the "Tone B"
soft key.
k. Move the cursor to Freq (frequency) and enter 08000.0 from the keypad.
l Move the cursor to the DTMF Code position and press the "DON'T CARE" soft key.
NOTE
The “more” soft key may have to be depressed for the “DON’T CARE” soft
key to be displayed.
m. Press the "return" soft key. Repeat steps A through K for presets 02 through 10. Use
Table 22 to program the frequency presets in steps D and E above.
n. Press the "return" soft key.
4. Perform the following steps to complete the setup on the R2600 analyzer.
a. Press RF key on the R2600 panel. Move the cursor to RF Control and press the "GEN"
soft key.
b. Move the cursor to the Output Lvl (RF Output Level) position and enter a level of -050.0
dBm from the keypad.
c. Move the cursor to the Gen RF Out position and press the "RF IN/OUT" soft key.
d. Depress the AUD (Audio) key on the R2600 panel. Move the cursor to the Synth
(Synthesizer) position and enter 70% from the keypad.
NOTE
This is AM Modulation. Depress the RIGHT ARROW CURSOR
CONTROL key and depress “Cont” (Continuous) soft key.
e. Move the cursor to the Fixed 1 kHz position. Depress the LEFT ARROW CURSOR
CONTROL key and then depress the "Off" soft key.
f. Verify the DTMF position and the External position are both OFF.
g. Depress the DISP (Display) key on the R2600 panel. Move the cursor to the Meter
position and depress the "AC VOLTS" soft key.
