Quarterly Maintenance Procedures
94 S
®
Booms • Z
®
Booms Part No. 1268489GT
8 Activate and hold the aircraft protection
override switch.
9 Activate each function control handle or toggle
switch.
Result: All boom, drive and steer functions
operate.
10 Fully retract the primary boom.
11 Raise the primary boom to 5° above
horizontal.
12 Move the yellow bumper at the bottom of the
platform 4 inches/10 cm in any direction.
13 Activate each function control handle or toggle
switch.
Result: No boom, drive or steer functions
operate.
14 Activate and hold the aircraft protection
override switch.
15 Activate each function control handle or toggle
switch.
Result: All boom, drive and steer functions
operate.
16 Lower the primary boom to the stowed
position.
Articulated (Z) Booms:
17 Raise the secondary boom approximately 3 ft /
1 m.
18 Move the yellow bumper at the bottom of the
platform 4 inches/10 cm in any direction.
19 Activate each function control handle or toggle
switch.
Result: No boom, drive or steer functions
operate.
20 Activate and hold the aircraft protection
override switch.
21 Activate each function control handle or toggle
switch.
Result: All boom, drive and steer functions
operate.
22 Lower the secondary boom to the stowed
position.

Genie Z Series Specifications

General

Lift Capacity	500 lb (227 kg) to 660 lb (300 kg)
Gradeability	30%
Power Source	Diesel, Electric
Capacity	500 lb (227 kg) to 1, 000 lb (454 kg)
Drive System	4-wheel drive
Tire Type	Solid
Steering	2-wheel or 4-wheel
