Genie Z Series User Manual

April 2018 Maintenance Manual
Programmed Maintenance Procedures
Part No. 1268489GT S
®
Booms • Z
®
Booms 159
Perkins Models
403D-11, 403F-11, 404D-22, 404F-22,
404F-22T, 804D, 1104D-44T
• Water pump - inspect
• Fuel Injector - test/change
• Cooling system coolant (Heavy Duty) -
change
403F-11
• Coolant temperature regulator - replace
404F-22, 404F-22T
• Coolant temperature regulator - replace
• Diesel particulate filter - clean
• Glow plugs (ARD combustion) - replace
• Radiator cap - inspect/replace
854F-34T
• Alternator - inspect
• Alternator and fan belts - replace
• Diesel particulate filter - clean
• Radiator cap - inspect/replace
Kubota Models
Z482-E, D-1105-E3B
• Turbocharger - inspect
• Injection pump - check
• Fuel injection timing - check
P4-1
Perform Engine Maintenance –
4000 Hours
Engine specifications require that this procedure be
performed every 4000 hours.
Required maintenance procedures and additional
engine information are available in the
manufacturer's manuals. Refer to Specifications,
Engine Operator and Maintenance Manuals.
Perkins Models
854F-34T, 1104D-44T
• Aftercooler core - clean/test

Genie Z Series Specifications

General

Lift Capacity	500 lb (227 kg) to 660 lb (300 kg)
Gradeability	30%
Power Source	Diesel, Electric
Capacity	500 lb (227 kg) to 1, 000 lb (454 kg)
Drive System	4-wheel drive
Tire Type	Solid
Steering	2-wheel or 4-wheel
