Genie Z Series User Manual

Maintenance Manual April 2018
Programmed Maintenance Procedures
152 S
®
Booms • Z
®
Booms Part No. 1268489GT
SX-105 XC / SX-125 XC / SX-135 XC
SX-150 / SX-180
Primary boom wear pad specifications
Minimum
Platform end
Bottom and side wear pads
0.63 in
16 mm
Top wear pads
(SX105 XC, SX125 XC, SX135 XC #1 to
#2)
(SX150, SX180 #1 to #2; #2 to #3)
(SX125 XC, SX180 #0 to #1)
0.35 in
9 mm
Top wear pads
(SX105 XC, SX125
XC, SX135 XC #2 to
#3)
0.63 in
16 mm
Top wear pads
(SX150, SX180 #3 to #4)
0.47 in
12 mm
Pivot end
Top wear pads
0.63 in
16 mm
Side wear pads
0.47 in
12 mm
Grease Specification
Lube a Boom grease
Genie part number
110147
Z-30/20N (RJ), Z-34/22N, Z-34/22DC
Models without rotating jib boom
Primary boom wear pad specifications
Minimum
Top, bottom and side wear pads
(extension end of boom)
0.625 inch
15.9 mm
Bottom and side wear pads
(pivot end of boom)
0.625 inch
15.9 mm
Top wear pads
(pivot end
of boom)
0.375 inch
9.5 mm
Models with rotating jib boom:
All wear pads
0.375 inch
9.5 mm
Z-33/18
Primary boom wear pad
specifications
Minimum
Top wear pads
- platform end
0.6875 inch
17.46 mm
Side wear pads
- platform end
0.5625 inch
14.29 mm
Bottom wear pads
- platform end
0.625 inch
15.9 mm
Top and side wear pads
- pivot end
0.69 inch
17.46 mm
Bottom wear pads
- pivot end
0.81 inch
20.64 mm
Z-34/22 IC, Z-34/22 Bi-Energy
Primary boom wear pad specifications
Minimum
Top, bottom and side
wear pads - platform
end
0.625 inch
15.9 mm
Bottom wear pads
- pivot end
0.50 inch
12.7 mm
Top wear pads
- pivot end
0.625 inch
15.9 mm
Side wear pads
- pivot end
0.375 inch
9.5 mm
Z-40/23N (RJ)
Primary boom wear pad
specifications
Minimum
Top and
side wear pads
(platform end of boom)
0.625 inch
15.9 mm
Bottom wear pads
(platform end of boom)
0.375 inch
9.5 mm
Top, bottom and side wear pads
(pivot end of boom)
0.375 inch
9.5 mm

Genie Z Series Specifications

General

Lift Capacity	500 lb (227 kg) to 660 lb (300 kg)
Gradeability	30%
Power Source	Diesel, Electric
Capacity	500 lb (227 kg) to 1, 000 lb (454 kg)
Drive System	4-wheel drive
Tire Type	Solid
Steering	2-wheel or 4-wheel
