To open the panel door
Fixing screws
Backbox Electronic module
Door
The panel
door
can be opened using the
allen key
supplied in the spares pack.
Partially open the two
fixing screws
and then hinge
open the panel door.
Note the information on the panel and labels inside
the enclosure.
CAUTION
HAZARDOUS VOLTAGE REMAINS
AFTER OPERATION OF FUSE
Product : SYSTEM 800
Rated Voltage: 230v a.c.
Rated Current: 0.3A
Rated Frequency: 50Hz
Mains Fuse FS7: 3.15A (T)
Manufac Date xx/xx/xx
LXXXX-X
OPENING THE DOOR EXPOSES LIVE PARTS
Danger
