To set auxiliary relay operation
(eg to operate with fire, fault, disablement, pre-alarm or off)
A2
min
Press select to scroll to
the required selection:
NOT CONNECTED
COMMON FIRE
(Default)
COMMON FAULT
COMMON DISABLEMENT
PRE ALARM
Select
Press to select a field [ ]
Previous Next
Auxiliary relay output: To silence on:
A2
A3
Select
Press select to to
gg
le
selection between:
SYSTEM RESET
(Default)
SILENCE ALARMS
Select
1
2
3
P1
EEPROM enable
1
2
3
P1
EEPROM enable
Press select
to scroll to
state:
ENABLE
DISABLE
Select
Auxiliary relay
Status:
A2
Only configure the hardware link
when setting the
of auxiliary relay.
o
p
eration
