Gent System 800 - To Select 2-Detectors or 2-Zones Coincidence Detection39

796688 (4188-657)_i2 _06/03
39
To select 2-detectors or 2-zones coincidence detection
Press to select [Zone] field
Previous Next
Select
A4
Press to select [Linked to zone] field
Previous Next
Select
1
2
3
P1
EEPROM enable
1
2
3
P1
EEPROM enable
The 2-detector coincidence can
only be applied to the selected
zone.
Press Select to chan
g
e
to a required 2nd zone
number of
two zone coincidence.
Press Select to chan
g
e to a required
zone number
Press to select [Mode] field
Previous Next
Press Select to to
gg
le to
2-DETECTOR / 2-ZONES.
NORMAL,FA-REJECTION,
Select
Select :2 DETECTOR for two detector coincidence,
2 ZONE for two zone coincidence.
Procedures
for 2 zone
coincidence only.
If 2 zones coincidence detection
is selected it is important to link
the selected zone to another zone.
