Light indications
Indication
Light
colour Status of light and meaning
Fire
(Red)
STEADY
– There is one or more fire(s) in the
system.
OFF
– There are no fire(s) in the system.
Fault
(Yellow)
STEADY
– There is at least one fault in the system,
view the fault log for details.
OFF
– There are no faults.
Pre Alarm
(Red)
STEADY
– There is at least one coincidence zone /
device in the pre alarm state.
OFF
– There are no zones/device in coincidence fire.
Power
(Green)
STEADY
– The mains & battery are healthy
OFF
– The panel has no mains supply or battery
supply.
System fault
(Yellow)
STEADY
– There is a system fault (MCU failure and
non-volatile memory corruption).
OFF
– There is no system fault.
Power fault
(Yellow)
STEADY
– There is either a mains or battery supply
fault.
OFF
– There is no power fault.
FRE Disablement
(Yellow)
STEADY
– The fire routing equipment (FRE) is
disabled.
OFF
– The FRE is not disabled.
FRE fault
(Yellow)
STEADY
– There is a fault with fire routing
equipment.
OFF
–There is no fault with fire routing equipment.
Fire Protection Activated
(Red)
STEADY
– The fire protection output has been
activated and there is an automatic fire call out.
OFF
– The fire protection output is not active.
Fire Routing Activated
(Red)
STEADY
– The fire routing output is active.
OFF
–The fire routing is not active.
Sounder fault
(Yellow)
STEADY
– There is a sounder circuit open or short
circuit fault.
OFF
– There is no sounder circuit fault.
