Gent System 800 - To Set Fault Routing Operation (Eg Activation Type)

796688 (4188-657)_i2 _06/03
47
To set fault routing operation
(eg activation type)
Press to to
gg
le selection
between:
NOT ACTIVATED
ACTIVATED
Select
Press to to
gg
le selection
between:
ENABLED
DISABLED (Default)
Select
A2
min
A2
A3
Press to select field [ ]
Previous Next
Press to select field [ ]
Previous Next
Press to select field [ ]
Previous Next
[C urrent state] [Status]
1
2
3
P1
EEPROM enable
1
2
3
P1
EEPROM enable
Only configure the hardware link
when setting of the
fault routing output.
status
