Product data
System 800 fire alarm panel
Standards EN54 Part 2 & Part 4
Number of Zone 24 zones per panel
Devices on loop 127 maximum
Battery supply 2 x 12V 7Ah
Standby period 24 hour standby + 0.5 hour alarm
Repeat panel output To output to repeat indicator units
(up to 2 maximum per system)
Common fault output Voltage free change over contacts rated 2A @ 30V
Common fire output Voltage free change over contacts rated 2A @ 30V
24V supply out 24V output
Sounder circuits and load 2 sounder circuits per panel 0.45A each
protected by auto reset thermal fuse
Sounder End of line resistor 10K ohms resistor
Auxiliary output Voltage free change over contacts rated 2A @ 30V
External power supply input
and monitoring
24V with mains and battery fail output
Panel Enclosure ABS
Colour Light blue-grey - Pantone 538
Dimension Height 375mm x Width 355mm x Depth 115mm
Approval Applied for LPCB approval
Approximate Weight
(without batteries)
3.1Kg
IP rating IP 31
Operating temperature 0ºC to 50ºC
Storage temperature -20ºC to 60ºC
Terminal size All terminals can accept a cable with a maximum of 2.5mm²
cross section area
Cable entry points Top and back
Mains supply 230V AC 50Hz (+10% -15%)
Factory set access codes Access level 2 – 2222 (timeout 3 minutes)
Access level 3 – 3333 (timeout 3 minutes)
Access level 4 – 4444 (timeout 4 hours)
