Geotech GA5000 User Manual

GA5000 gas analyser OMGA5KN4.4
 Copyright Geotech Page 15 of 113
4.1.4 Gas analyser manager – GAM (optional)
Gas Analyser Manager (GAM) enables the operator to maximise the operation of the gas
analyser. It enables direct communication with the unit, features a simple upload and
download facility and is fully compatible with the latest Microsoft™ operating systems.
Features:
 Organisation and transfer of borehole IDs and readings to and from the gas
analyser.
 Configuration of the gas analyser.
 Flexible grouping of the IDs.
 Structured organisation of transferred data.
 Automatic detection of instrument type and available options.
 Secure data mode to prevent tampering.
 First time set-up wizard.
 Enable flow measurements for GA5000 gas analysers.
4.1.5 GPS (optional)
An optional GPS feature is available for the GA5000 gas analyser. It enables the site
engineer to automatically locate borehole IDs using GPS satellite signal from predefined
borehole IDs uploaded from Gas Analyser Manager or set on the analyser when out in the
field prior to taking a reading. The GPS reading data is stored for each measurement
reading providing an audit trail confirming that a reading was taken.
4.1.6 Bluetooth
The analysers are fitted with a Bluetooth receiver which enables the operator to
download readings and upload IDs without the need to connect the analyser to a PC via a
USB lead.
4.1.7 Internal Flow (optional)
The GA5000 gas analyser has the capability to measure the gas flow from a borehole
without the need for an additional flow pod. The user is automatically prompted to take
this measurement during the normal reading sequence. This function can be selected as
‘On’ or ‘Off’ for each ID using Gas Analyser Manager. If it is off the user will not be
prompted to measure the flow.
