Geotech GA5000 User Manual

OMGA5KN4.4 GA5000 gas analyser
Page 18 of 113  Copyright Geotech
5.2 Analyser features and keys
Ref
Feature
Function
A
Main Read Screen
Start and end screen when using the instrument.
B
Soft-keys
The function of the three ‘soft-keys’ on the front of
the instrument panel is determined by menu
options taken. Functions vary from screen to
screen.
C
Backlight Key
Enables the operator to turn the backlight on/off
on the analyser display panel.
D
Menu Key
Press the ‘Menu’ key to view and maintain User,
Device and Operation settings.
E
Pump Key
Press the ‘Pump’ key to start or stop the pump.
F
LED Light
LED power light is visible on the front of the
analyser when the instrument is powered on.
G
On/Off Key
Press the ‘On/Off’ key for 2 seconds to switch the
instrument on and off.
H
Assistance key
Press for on-screen assistance and help.
I
Enter key
Used to accept
J
Scroll up key
Also ‘Key 2’. Press scroll up to view further
information on the instrument screen.
K
Scroll down Key
Also ‘Key 8’. Enables the operator to scroll down
to display more information.
L
Key 0 – Space key
Also ‘Key 0’. Press to enter a space when entering
text on the instrument screen.
M
Model Number
Instrument model type identification.
N
Serial Number
Unique identification for the instrument.
Verification of the serial number will be required if
Technical Support assistance is needed.
O
Part Number
Manufacturer’s part number.
P
Recalibrated Due
The date displayed is the date the instrument is
Q
Certificated Number
Displays instrument certification information.
