GeoVision GV-FD220D User Manual

Mini Fixed & Rugged Dome
6
6.3.3 GV-MDR
1
2
3
4
5
6
7
8
9
10
11
Figure 6-4
No. Name Description
1 Silica gel bag Absorbs the moisture inside the camera.
2 Conceal paper
Prevents water or moisture from entering
the camera.
3 Lens Receives image inputs.
4 Rotation Disc Rotates the camera lens.
5 Pan Disc Pans the camera lens.
6 Tilt Screw Loosens to tilt the camera.
7 Microphone Provides one-way audio.
69
