Specifications: Target Box Camera
531
Operation (Focus / Zoom /
Iris)
Fixed
IR LED Quantity 8 IR LEDs
Max. IR Distance 15 m (50 ft)
Operation
Video Compression H.264, MJPEG
Video Stream Dual streams from H. 264 or MJPEG
Frame Rate 30 fps at 1280 x 1024
Image Setting
Brightness, Contrast, Saturation,
Sharpness, Gamma, White Balance,
Flicker-less, Image Orientation, Shutter
Speed, D/N Sensitivity, Backlight
Compensation, WDR, Defog
Audio Compression G.711, AAC (Optional)
Audio Support One-Way Audio
Note: The frame rate and performance may vary depending on the number of
connections and data bitrates (different scenes).
Video Resolution
4:3 1280 x 960, 640 x 480, 320 x 240
16:9 1280 x 720, 640 x 360, 448 x 252
Main
Stream
5:4 1280 x 1024, 640 x 512, 320 x 256
4:3 640 x 480, 320 x 240
16:9 640 x 360, 448 x 252
GV-EBX1100
Series
Sub
Stream
5:4 640 x 512, 320 x 256
