GeoVision GV-FD220D User Manual

208
14.5.3 Voltage Load Expansion (Optional)
The camera can only drive a maximum load of 200mA 5V DC. To expand
the maximum voltage load to
10A 250V AC, 10A 125V AC or 5A 100V DC,
connect the camera to a GV-Relay V2 module (optional product). Refer to
the figure and table below.
Output Devices
Connect to Power
Figure 14-17
GV-Relay V2 Vandal Proof IP Dome
COM Ground (Yellow)
DO1 Digital Out (Brown)
