5.4 Installation
The IR Arctic Box Camera is designed for outdoor use. Follow the steps
below to install your camera.
1. Mark the installation site and drill four holes for screw anchors.
2. Insert the supplied screw anchors.
3. Secure the camera to the wall using the supplied washers and screws.
Figure 5-3
4. Connect the camera with wires and cables. See 5.5 Connecting the
Camera.
5. Access the live view. See 19.1 Accessing the Live View.
6. Based on the live view, adjust the angle of the camera. Loosen the
indicated screw with the supplied big torx wrench and adjust the joint.
Figure 5-4
44
