H. Power Supply Support List

The supported power type is indicated with a tick (9) and the unsupported

power type with a cross (8).

GV-IP Camera DC Power AC Power PoE

Box Camera 9 8 9

Ultra Box Camera 9 8 9

Target Box Camera 9 8 9

GV-BX120D-E

GV-BX220D-E

GV-BX320D-E

GV-BX520D-E

GV-BX1500-E

GV-BX2400-E

GV-BX3400-E

GV-BX5300-E

8 8 9

IR Arctic Box

Camera

GV-BX2510-E

GV-BX5310-E

9 9 9

Mini Fixed Dome 9 8 9

Mini Fixed Rugged Dome 8 8 9

Target Mini Fixed Dome 9 8 9

Target Mini Fixed Rugged Dome 9 8 9
