Specifications: Advanced Cube

Camera

Image Sensor

1/2.5’’ progressive scan CMOS

GV-CA120

GV-CAW120

1280 (H) x 1024 (V)


Elements

GV-CA220

GV-CAW220

1920 (H) x 1080 (V)

Color

0.15 Lux

B/W

0.10 Lux

Minimum

Illumination

LED on

0 Lux

Shutter Speed

Automatic, Manual (1/5 ~ 1/8000 sec)

White Balance

Automatic, Manual (2800 ~ 8500K)

Gain Control

Automatic

S/N Ratio

45 db

WDR

Yes

Dynamic Range

Up to 72 dB

Lens

Megapixel

Yes

Day/Night

Yes (electronic)

Lens Type

Fixed

Focal Length

3.35 mm

Maximum Aperture

F/2.4

Mount

M12 mm
