Fixed IP Dome
16
16.4.3 Wall-Surface Mount
Figure 16-18
1. Follow step 2 in 16.4.1 Hard-Ceiling Mount section to remove the
housing cover and take out the camera body.
2. Paste the supplied sticker onto a desired location on the wall. Drill the
three red dots, and the ellipse mark only if you wish to run the wires
into the wall.
3. Insert the short screw anchors and secure the camera and the
mounting plate with three plate screws.
Figure 16-19
4. Connect the network, power and other cables to the camera. See
16.5 Connecting the Camera.
247
