4.3 Overview

Figure 4-1

No. Name Description

1 Default

Resets the camera to factory defaults.

See 23.3 Restoring to Factory Default

Settings.

2 LAN / PoE Connects to a 10/100 Ethernet or PoE.

3 Microphone Records sounds.

4 DC 12V Terminal Block Connects to power.

LED Indicator Description

Status LED

The status LED turns on (green) when the system

is ready for use.

Power LED

The power LED turns on (green) when power is

supplied to the camera.
