11.3 Overview

Panel

Figure 11-1

No. Name Description

Power

Connector

Connects to the data cable. For details, see

11.5 Connecting the Camera.

2 Default Button

Resets all configurations to factory default.

See 23.3. Restoring to Factory Default

Settings.
