Vandal Proof IP Dome (Part I)
14
14.5.2 Power Connection
There are two ways to supply power to the camera:
• Use a Power over Ethernet (PoE) adapter to connect the camera to the
network, and the power will be provided at the same time.
• Plug the power adapter to the 12V terminal block as shown below. The
power adapter is an optional device. For detail, see Options in the
manual.
1. Insert the thin black wire of the Vandal Proof IP Dome to the left
pin and the red wire to the right pin.
Figure 14-15
2. Connect the DC 12V Power Adapter to the Terminal Block.
DC 12V Power Adaptor
Terminal Block
Figure 14-16
207
