GeoVision GV-FD220D User Manual

Vandal Proof IP Dome (Part I)
14
14.4.2 In-Ceiling Mount
Figure 14-8
1. Follow step 1 in 14.4.1 Hard-Ceiling Mount section to remove the
housing cover, thread lock and back cover, and take out the camera
body.
2. Cut out a circle with a diameter of 142 mm on the ceiling.
3. Insert a blue screw to the indicated holes on the camera body.
Figure 14-9
203
