Target Mini Fixed Dome

7.4 Installation

The Target Mini Fixed Dome can be installed on the wall or the ceiling.

Before installing the camera, make sure the installing site is shielded from

rain and moisture.

1. Open the housing cover by turning.

Figure 7-2

2. Place the camera where you want to install it and make 2 marks on

the ceiling or the wall for screw anchors. If you want to run the cables

inside the ceiling or the wall, make a round mark with a diameter of

2.5 cm.

Figure 7-3
