4. From the side with the numbering, secure the copper pillars with 3

copper pillar screws.

Figure 16-12

5. Place the 3 mounting brackets at the indent next to the copper pillars

(labeled as 2 on the mounting plate) and secure them using the 3

bracket screws.

Figure 16-13
