Plotter Adjustment 65
20. Power on the plotter. The Theta axis is locked for approximately 3
minutes.
21. Locate the rear way collar clamp. Use the Allen wrench to loosen
the collar clamp.
22. Rotate the knife holder by hand until the blade is properly aligned,
as explained in step 15. Tighten the clamp.
23. Turn the power off to unlock the theta axis.
24. Press and turn the knife holder out of alignment. Power-up the
plotter to the normal off-line state. The blade in the knife holder
must return to the correct alignment. If not, turn the plotter power
off. Return to step 20.
Note: You may need to repeat steps 20 through 24 several times to
obtain correct alignment.
25. When the blade is correctly adjusted, power-up the plotter while
holding the RESET key. Load paper and install knife holder.
26. Press the down arrow to run the X08 test cut. Press either RUN key
to cut. Inspect your test cut.
If symptoms persist, call Gerber Field Service Department at
800-828-5406, or fax at 203-645-2448.
