Plotter Adjustment 81
GS15
plus
PLOTTER USER REFERENCE CARD
KEY/FUNCTION DESCRIPTION
RUN SINGLE Key
Plot Press RUN SINGLE to plot single jobs. The GS15
plus
returns to the off-line status
(as at power-up) after each job and waits for the operator to press RUN SINGLE key
again to plot the next job.
Controlled Stop Press either RUN key to stop plotting at the next logical break in the program and
check current job. Do not use slew keys or the orientation for the current job will be
lost.
RUN CONT Key
Plot Press RUN CONT to plot two or more jobs continuously. The GS15
plus
plots one job
after the other without pausing between them and remains on-line until either RUN
key is pressed.
Controlled Stop Press either RUN key to stop plotting at the next logical break in the program and
check current job. Do not use slew keys or the orientation for current job will be lost.
Slew Keys (Arrow Keys)
The arrow and SLOW keys do not function while a job is plotting, during an error
condition, or while a RUN light is on, even if the plotter is idle.
Press arrow keys to position carriage and material between jobs:
! Up and down arrow keys move the carriage spindle between the rear and the
front of the plotter.
! Left and right arrow keys rotate the drum and feed material through the plotter or
back toward the roll holder.
Slow Key
Hold the SLOW key while simultaneously pressing any Arrow key. This slows
carriage movement for exact positioning.
Reset Key
Emergency Stop Press RESET key to stop GS15
plus
operation, clear the current job from the buffer,
and return the plotter to off-line status.
Clear Press the RESET key to stop the error signal after a power-up or plotting failure. (See
Error Conditions Section.)
Access Hold the RESET key at power-up to access additional diagnostics. (See Special
Diagnostics Section.)
