GS15
plus
PLOTTERERRORCODES
ERROR
CODE
DESCRIPTION OPERATOR RESPONSE
1 Program checksum failure Try power-up again.
2 RAM memory failure Try power-up again.
3 RS-232 test failure Try power-up again.
4 Illegal plot data command Check plot data; resubmit job.
5 Corrupt data Check plot data; resubmit job.
6 Buffer overflow Call Gerber Field Service.
7 UART error Occurs as part of self-test; try power-up again.
8 *Z axis lock time-out Power-up again while holding down the RESET key
9 Z axis error Turn off the system; check connectors.
10 Theta home failure Turn off the system; check connectors.
Note: If the GS15
plus
consistently fails the self-check tests, contact Gerber Field Service Department.
SUGGESTED GS15
plus
TOOL FORCE SETTINGS
Material Recommended
Starting Tool Force
Tangential
Knife Blade
GS Plotter Swivel
Knife
Controltac 180
Delux 210 Gold/Silver
Dusted Crystal 210 .05-1
30 ° GS 35°
Florescent 210
Scotchcal™ 220
Translucent 230
Gerber Cal®
Gerber IP Plus
GerberMask™ I & II 1
30° GS 35°
Heat Transfer Flock
Hot Split Plastisol
Metalized Polyester
Screen Print .05
30° GS 35°
Static Cling
Sandblast 521 4-5
45° or 60°
Sandblast 522
Service Department 800-828-5406 Fax 203-645-2448 International Customer Service 203-643-5716
