| 44 | 3 Inspection | CARDIOHELP System |
Service Manual | 3.3 | EN | 05
Copyright Maquet Cardiopulmonary GmbH
6 In order to check the upper fan place the measuring tool at the 3rd
ventilation rib from the top.
Upper fan check
▶ The upper fan operates correctly if the measured value is between 0.5 m/s and 1.1 m/s.
▶ The upper fan operates not correctly if the measured value is between 0 m/s and 0.5 m/s.
u Fan check - passed/failed.
Check Licensing and Country Settings
1 Touch the [Menu] symbol.
2 Touch the [Application] symbol.
Call up configuration screen
▶ The [Application] screen is displayed.
▶ Licensing for CARDIOHELP XVIVO.
CARDIOHELP application
▶ Rotary knob cover without labeling.
▶ Licensing for CARDIOHELP-i.
CARDIOHELP-i applications
▶ Rotary knob cover with labeling “CARDIOHELP-i“.
NOTE
CARDIOHELP-i application screen is different between United States of America and the rest of the world.
