| CARDIOHELP System | 3 Inspection | 55 |
Service Manual | 3.3 | EN | 05
Copyright Maquet Cardiopulmonary GmbH
Start PC-Aided Function Test
1 Connect the HLS test circuit (⇨ "Connecting the Test Circuit",
page 34).
HLS test circuit
2 Connect the laptop to the CARDIOHELP with the USB cable.
3 Activate the service interface (⇨ "Activate the Service Interface", page 79).
4 Start the Service Tool Software on the laptop.
Check the Alarm Chain
1 Open the [Function test] tab.
Service Tool, Function test
2 Click on the [Alarm chain] button.
3 Follow the instructions on the screen.
▶ After a successful test, the message [Test OK] appears.
Test OK
4 Click on the [OK] button.
