ProfiLux 4 Resource Guide
EN 2018-13-11 113
CREATE THE PL FUNCTION: Combine Feed Pause and Leakage Detection
1. Go to the PROGRAMMABLE LOGIC settings page
2. Select an unused
Gate
and set the function to AND.
3. Set
Input 1
to FILTER and select the Filter (Feed pause) number to assign.
4. Set
Input 2
to FILL WATER and select the Control circuit number where the Leakage
Detection function was created.
5. Type-in a description and click OK.
ASSIGN THE PL FUNCTION TO A POWERBAR OUTLET
1. Go to the SWITCH CHANNELS AND OUTLETS settings page and select the Powerbar
outlet that has the skimmer connected to it.
2. Set this function to PROGRAMMABLE LOGIC and select the
Gate
number you used when
you created the PL function.
a. For example, if you selected Gate 1 (G1) to create the PL function, select
PROGRAMMABLE LOGIC 1.
3. Type-in a description and click OK.
4. Click SAVE CHANGES.
Combining Feed Pause AND Timer function (Using OR function)
Scenario: If you want to run the skimmer off of a TIMER and also want it to turn OFF when a
feed pause is activated, you will want to combine these two functions using the Programmable
Logic (OR) function.
Here’s how to combine a Feed Pause and Timer function using the OR function:
CREATE THE PL FUNCTION: Combine Feed Pause and Timer
1. Go to the PROGRAMMABLE LOGIC settings page
2. Select an unused
Gate
and set the function to OR.
3. Set
Input 1
to FILTER and select the Filter (Feed pause) number to assign.
4. Set
Input 2
to TIMER and select the timer number you want to assign.
5. Type-in a description and click OK.
ASSIGN THE PL FUNCTION TO A POWERBAR OUTLET
1. Go to the SWITCH CHANNELS AND OUTLETS settings page and select the Powerbar
outlet that has the skimmer connected to it.
