ProfiLux 4 Resource Guide

EN 2018-13-11 114

2. Set this function to PROGRAMMABLE LOGIC and select the

Gate

number you used when

you created the PL function.

a. For example, if you selected Gate 2 (G2) to create the PL function, select

PROGRAMMABLE LOGIC 1.

3. Type-in a description and click OK.

4. Click SAVE CHANGES.

Combining multiple PL functions (Using AND function)

Scenario: If you want to assign more than 2 functions to a Powerbar outlet, you can do so by

creating your PL functions, then using a new PL gate to assign those PL functions to the new PL

function. For example, if you want to have a skimmer react to 3 separate functions:

 Turn ON from 8am – 8pm (Timer function)

 Turn OFF during a Feed Pause (Filter function)

 Turn OFF if sump water level gets too high (Fill water assigned for Leakage Detection)

You would use 2 Programmable Logic functions where the first PL function (Gate 1) would have

Input 1

assigned to TIMER function,

Input 2

would be assigned to FILTER function, and PL

function itself assigned as an AND function.

You would then select another PL function (Gate 2).

Input 1

would be assigned

PROGRAMMABLE LOGIC (X) with X being the gate number you used earlier. Input 2 would be

assigned to FILL WATER (X) with X being the Control circuit number you used when you

created the LEAKAGE DETECTION function. It would look like this:
