ProfiLux 4 Resource Guide
EN 2018-13-11 62
Do you have more than 1 heater?
Those that have more than 1 heater can apply the same temperature control
function to multiple heaters. Simply select the powerbar outlet that has the
other heater connected and assign it the SAME function as you did earlier.
For example, with 2 heaters, one on outlet 1 and one on outlet 2, both
outlets would have the same TEMPERATURE HEATER function assigned.
Heaters and the Powerbar5.1 (S5) outlet
When choosing the outlet to connect your heater to, keep in mind that the
S5 outlet on the Powerbar5.1 has a MAX 2A rating.
Only equipment that uses less than 2A should be connected to this outlet.
TO DO: Setup return pump control
When it comes to having the ProfiLux 4 control your return pump(s), you have many options to
choose from. You can set the return pump to react to a feed pause, maintenance mode, control
the flow via 1-10V interface, stay always ON, etc. Simply pick the sub-section that applies to
you.

GHL ProfiLux 4 Specifications

General

Model	ProfiLux 4
Category	Controller
Power Supply	12V DC
pH Ports	2
Redox Ports	1
Conductivity Ports	1
Level Ports	4
Digital Inputs	4
12V Outputs	4
Real-time clock	Yes, with battery backup
Digital Outputs	4
Expandable	Yes
Connectivity	USB, Wi-Fi, LAN
Display	Graphic LCD display
Expansion Slots	4
Processor	32-bit
Channels	16
Operating Temperature	0°C to 50°C
