GHL ProfiLux 4 Resource Guide

ProfiLux 4 Resource Guide
EN 2018-13-11 94
Did you select Operation mode: ATO & Water
Change?
If during the AWC function setup you selected the Operation mode , ATO &
WATER CHANGE, you must select the outlet that has your ATO pump
connected and assign the function, FILL WATER (ATO ONLY).
How to setup Leakage detection
ProfiLux 4 comes equipped with a Leakage detection feature which can be set to notify you of a
leak. This feature can also be used to shut down certain Powerbar outlets in cases where a leak
is detected or shut down return pumps if the sump water level gets too low. This section will
show you how to setup Leakage detection and assign outlets to turn OFF in case of a leak or
low sump water level. First, you will create the function, then you will assign the function to an
outlet on your GHL Powerbar.
In order to setup standard Leakage detection, you will need certain items. These items can be
purchased at your preferred GHL dealer:
 PL-0851 – Leakage interface (For connecting to the P4 Controller)
 PL-0850 – Leakage sensor (For connecting to the Leakage interface)

GHL ProfiLux 4 Specifications

General

Model	ProfiLux 4
Category	Controller
Power Supply	12V DC
pH Ports	2
Redox Ports	1
Conductivity Ports	1
Level Ports	4
Digital Inputs	4
12V Outputs	4
Real-time clock	Yes, with battery backup
Digital Outputs	4
Expandable	Yes
Connectivity	USB, Wi-Fi, LAN
Display	Graphic LCD display
Expansion Slots	4
Processor	32-bit
Channels	16
Operating Temperature	0°C to 50°C
