ProfiLux 4 Resource Guide
EN 2018-13-11 76
How to setup 1-10V pump control
This section will show you how to control 1-10V pumps such as return pumps, Maxspect Gyre
pumps, and Tunze stream pumps. Since the applications for each pump will vary, the steps
below will provide a general overview of what you need to do to get your 1-10V pump up and
running. First you will connect the control cables to the ProfiLux 4, then you will assign the 1-
10V interface function, then configure the pump’s behavior.
DO YOU HAVE EVERYTHING YOU NEED?
In order for the ProfiLux 4 to control a 1-10V device, a GHL compatible
control cable is required. This control cable can be sourced from the pump
manfacturer. For example, Abyzz and Royal Exclusiv offer GHL compatible
control cables.
If a control cable is not available from the pump manufacturer or there is
only an RJ-45 control cable available, you can still connect it to the P4 by
cutting the end of the cable and connecting it to our 1-10V breakout box
accessory. This breakout box is then connected to the P4’s (Yellow) L-
channel port.
Have a controllable Tunze pump?
Tunze control cables for ProfiLux controllers are available at your preferred
GHL dealer.
PL-0087 ProfiLuxTunze1
PL-0088 ProfiLuxTunze2
Tunze1 cables are for odd-numbered L-channels.
Tunze2 cables are for even-numbered L-channels.
For example, 3 pumps will need 2x T1 cables and 1x T2 cable. (Pump #1
connected to the P4‘s – L1 (Yellow) port, Pump #2 – L2 port, Pump #3 – L3
port)
1x 1-10V port = 2x 1-10V channels
Each 1-10V (Yellow) L-channel port on the ProfiLux 4, expansion cards, and
expansion box are capable of controlling 2 separate 1-10V channels. You can
access both channels by using our
YL2 splitter cable
accessory offered in 3
sizes, 1m, 2.5m, 5m.
CONNECT CONTROL CABLE
