ProfiLux 4 Resource Guide

EN 2018-13-11 75

To activate this feature, please follow these steps:

1. Select an ILLUMINATION channel.

2. Check the box, TEMP.-DEP. LIGHT REDUCTION.

3. Repeat steps 1 and 2 if you want multiple Illumination channels to react to this feature.

4. Under the Illumination drop down list, select TEMP.-DEP. LIGHTRED.

5. Select the Temperature probe that will be responsible for controlling the assigned

Illumination channel(s).

6. Set the SHUT OFF LIMIT.

 The number you set will determine when your lights would turn off. For example,

if your Temperature probe nominal temperature is set to 77°F and shut off limit

is set to 3°F, the assigned illumination channels will turn off for the day IF

temperature reaches 80°F and above.

7. Click SAVE CHANGES.
