How to setup Maintenance modes
ProfiLux 4 can be configured to temporarily shut down specific outlets, 1-10V devices, and
Mitras Lightbar. This feature is especially useful for manual water changes or general
maintenance tasks. When activated, specific devices will be turned OFF for a certain amount of
time, then turned back ON after the time has elapsed.
TIP
You can have up to 4 different maintenance modes.
To setup Maintenance mode, please follow these steps:
1. Click on the (+) icon to the left of Extras and select a MAINTEANCE option.
2. Select which Powerbar outlets you want to react to the selected MAINTENANCE mode.
 Select the desired outlets, then set them to either turn ON or turn OFF when this
Maintenance mode is activated.
3. If you have 1-10V devices, select which device you want to react and the percentage it
shall run at when Maintenance mode is activated.
4. If you have a Mitras Lightbar, select which channel will react and the percentage.
5. Type-in a description for this maintenance mode.

GHL ProfiLux 4 Specifications

General

Model	ProfiLux 4
Category	Controller
Power Supply	12V DC
pH Ports	2
Redox Ports	1
Conductivity Ports	1
Level Ports	4
Digital Inputs	4
12V Outputs	4
Real-time clock	Yes, with battery backup
Digital Outputs	4
Expandable	Yes
Connectivity	USB, Wi-Fi, LAN
Display	Graphic LCD display
Expansion Slots	4
Processor	32-bit
Channels	16
Operating Temperature	0°C to 50°C
