GHL ProfiLux 4 Resource Guide

ProfiLux 4 Resource Guide
EN 2018-13-11 89
TIP: Sensor reaction time (Delay)
Some filtration systems have high-flow sumps which can trigger the sensor
when it is not neccessary.
If you wish to change the reaction time for specific level sensors, you can do
so here:
ASSIGNING THE FUNCTION
1. Click on the (+) icon to the left of System.
2. Select SWITCH CHANNELS AND OUTLETS.
3. Select the outlet that has the ATO pump connected to it.
4. Set the function to FILL WATER (ATO ONLY) and select the Control Circuit number you
used when you created the ATO function.
 For example, if you created the function on Control circuit 1, set the function to
FILL WATER (ATO ONLY) 1. If Control circuit 2 was used, set the function to FILL
WATER (ATO) ONLY 2.
5. Type-in a description in both fields, set a black-out delay if necessary, and then click OK.
6. Click SAVE CHANGES.

GHL ProfiLux 4 Specifications

General

Model	ProfiLux 4
Category	Controller
Power Supply	12V DC
pH Ports	2
Redox Ports	1
Conductivity Ports	1
Level Ports	4
Digital Inputs	4
12V Outputs	4
Real-time clock	Yes, with battery backup
Digital Outputs	4
Expandable	Yes
Connectivity	USB, Wi-Fi, LAN
Display	Graphic LCD display
Expansion Slots	4
Processor	32-bit
Channels	16
Operating Temperature	0°C to 50°C
