ERROR MESSAGE
Cause of Trouble / How to troubleshoot
If the communication (RS232C) between the main PCB & display PCB is in trouble, the message
as the above picture would be blinking for every 0.5 sec till it would be recovered.
If the communication (RS232C) between the main PCB & display PCB is in trouble, the message
as the above picture would be blinking for every 0.5 sec till it would be recovered.
To display Alarm for Main Motor Drive.
If input/output voltage is not be at the Motor Drive or encoder for motor control is defective, LAMI DRIVE ALARM is occurred.
While this alarm is cured, if the RUN button is pressed, the alarm message is displayed for 3 secs.
To release from alarm, press STOP button for 1 sec on SUB2 Mode.
