How to use the Main Devices
☞ Film Position
In accordance with Single Side Lamination condition, the substrate width has to be wider than the film width by 5~10mm.
Otherwise, the roller can be contaminated / damaged by glue on the Film.
Position the Film at the inside of the substrate end by 3~5mm as the below picture.
WARNING : Film width has to be smaller than the substrate width by 5~10mm.
Otherwise, this could be a cause of trouble / error.
☞ SIDE SLITTER & REWINDER
To slit the film width if the film roll width is wider than the substrate's one.
Position the Side Slitters as the right pictures and slit it.
Rewind the Slitted films at the Rewinder.
NOTE : This device has Up/Down Moving Structure for easy film loading.
WARNING : Blade is very sharp. Be careful for installation.
This could be a cause of injury.
Loading of Laminating Films
Slit film with Side Slitters & Rewinder
